55UH5J-H, New High Haze UHD Standard Signage, UHD Signage, UH5J-H

คุณสมบัติสินค้า:

SKU : 55UH5J-H

Share

Key Feature

  • Brightness(Typ.) : 500 nit
  • Surface Treatment (Haze) : 28%
  • Bezel : 9.9 mm (T/R/L), 14.4 mm (B)
  • Depth : 39.9 mm
  • Interface : HDMI(3)/ DP/ DVI-D/ USB 2.0/ RS232C/ RJ45/ Audio/ IR
  • Built-in Speaker
Tech Spec
Panel
  • Screen Size  :  55"
  • Panel Technology  :  IPS
  • Back Light Type  :  Edge
  • Aspect Ratio  : 16:9
  • Native Resolution  :  3,840 X 2,160 (UHD)
  • Refresh Rate  :  60 Hz
  • Brightness (Typ.)  :  500 nit
  • Contrast Ratio  :  1,100:1
  • Dynamic CR  :  1,000,000:1
  • Color gamut  :  BT709 95%
  • Viewing Angle (H x V)  :  178 × 178
  • Color Depth  :  10 bit (D), 1.07 Billion colors
  • Response Time  :  8 ms (G to G)
  • Surface Treatment (Haze)  :  28 %
  • Life Time (Min.)  :  50,000 Hrs
  • Operation Hours (Hours / Days)  :  24 / 7
  • Portrait / Landscape  :  Yes / Yes



Mechanical Specification

  • Bezel Color  :  Black
  • Bezel Width  :  T/R/L: 9.9mm, B: 14.4mm
  • Weight (Head)  :  19.0 Kg
  • Weight (Head+Stand)  :  19.6 Kg
  • Packed Weight  :  24.2 Kg
  • Monitor Dimensions (W × H × D)  :  1,234.4 x 720.9 x 39.9 mm (with LG Logo)
  • Monitor Dimensions with Stand (W × H × D)  :  1,234.4 x 770.7 x 290.0 mm
  • Carton Dimensions (W × H × D)  :  1,360.0 x 835.0 x 175.0 mm (Box outer size)
  • VESA™ Standard Mount Interface  :  300 × 300 mm



Special Feature

  • Tilt (Facedown)  :  Yes (Max 30º degree, 30ºC temperature, humidity 50%)
  • IP Rating  :  IP5X



Key Feature (Hardware)

  • Internal Memory  :  16 GB
  • Wi-Fi  :  Yes
  • Temperature Sensor  :  Yes
  • Auto Brightness Sensor  :  Yes
  • Acceleration(Gyro) Sensor  :  Yes
  • Local Key Operation  :  Yes



Key Feature (Software)

  • webOS ver.  :  webOS 6.0
  • Embedded CMS  :  Local Contents Scheduling, Group Manager
    USB Plug & Play  :  Yes
  • Fail over  :  Yes
  • Image Customization  :  Booting Logo Image, No Signal Image
  • Multi-screen  :  PIP, PBP (4)
  • Screen Share  :  Yes
  • Sync Mode  :  RS-232C Sync, Local Network Sync
  • Video Tag  :  Yes (4)
  • Play via URL  :  Yes
  • Rotation  :  Screen Rotation, External Input Rotation
  • Gapless Playback  :  Yes
  • Tile Mode Setting  :  Yes (Max. 15x15)
  • Setting Data Cloning  :  Yes
  • SNMP  :  Yes
  • ISM Method  :  Yes
  • Auto Set ID  :  Yes
  • Status Mailing  :  Yes
  • Control Manager  :  Yes
  • 3rd Party Compatibility  :  Crestron Connected
  • Beacon  :  Yes
  • Power  :  Smart Energy Saving, PM mode, Wake on LAN, Network Ready
  • HDMI-CEC  :  Yes
  • SI Server Setting  :  Yes
  • webRTC  :  Yes
  • Pro:Idiom  :  Yes



Environment Conditions

  • Operation Temperature  :  0 °C to 40 °C
  • Operation Humidity  :  10 % to 80 %



Power

  • Power Supply  :  AC 100-240 V~, 50/60 Hz
  • Power Type  :  Built-In Power



Power Consumption

  • Typ./Max.  :  110 W / 150 W
  • Smart Energy Saving  :  77W
  • DPM  :  0.5W
  • Power off  :  0.5W
  • BTU (British Thermal Unit)  :  376 BTU/Hr(Typ.), 512 BTU/Hr(Max.)



Certification

  • Safety  :  0CB / NRTL
  • EMC  :  FCC Class "A" / CE / KC
  • ErP  :  Yes (NewErP)



OPS Compatibility

  • OPS Type Compatible :  Yes



Software Compatibility

  • SuperSign CMS  :  Yes
  • SuperSign Control / Control+  :  Yes
  • SuperSign WB  :  Yes
  • SuperSign Media Editor  :  Yes
  • LG ConnectedCare  :  Yes
  • Promota  :  Yes (Not available for EU/CIS)
  • Mobile CMS  :  Yes



Connectivity

  •  Input  :  HDMI (3, HDMI1/HDMI2 : HDCP 2.2/1.4 HDMI3 : HDCP 1.4), HDMI Out, DP In (HDCP2.2/1.3), DVI-D In (HDCP1.4), IR IN, USB (USB2.0 Type A(1))
  • Output  :  Audio In / Out
  • External Control  :  RS232C In / Out (4 Pin Phone Jack), RJ45 (LAN) In



Sound

  • Speaker  :  Yes



Language

  • OSD  :  English, French, German, Spanish, Italian, Korean , Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Turkish, Arabic



Accessory

  • Basic :  Remote Controller (include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
  • Optional :  Stand (ST-653T), Wall bracket (LSW350B), OPS Kit (KT-OPSF)
