55XF3E-B, XF Series, Open-frame Display

Key Feature

• Brightness : 3,000 cd/m² (Typ.)
• Life Time  :  50,000 hours
• Bezel Width  :  9.9 mm (L/R), 12 mm (T/B)
• Depth  :  106.8mm
• Interface  :  HDMI(2) / DP / DVI-D / RJ45 / RS232C / USB / External speaker out (L/R)

• Screen Size  :  55
• Resolution  :  1,920 x 1,080 (FHD)
• Brightness (Typ., cd/m²)  :  3000

• Bezel Width  :  9.9mm (L/R),12mm (T/B)
• Monitor Dimension (W x H x D)  :  1,235.5 x 709.4 x 106.8 mm
• Weight (Head)  :  26.5kg

• Input  :  HDMI (2), DP, DVI-D, Audio, USB
• Output  :  DP, External Speaker
• External Control  :  RS232C In/Out, RJ45 In, IR Receiver In

• Operation Temperature  :  0℃ to 50℃ (w/o Direct Sunlight or with Cooling Systems in Direct Sunlight)
• Operation Humidity  :  10 % to 80 %

• Power Supply  :  100-240V~, 50/60Hz
• Power Type  :  Built-In Power

• Typ./Max.  :  250 W / 300 W
• Smart Energy Saving  :  120 W

• Safety  :  IEC 60950-1 / EN 60950-1 / UL 60950-1
• EMC  :  FCC Class
• ErP  :  Yes (EU Only)

• Content Management Software  :  SuperSign CMS
• Control and Monitoring Software  :  SuperSign Control+ / Control

• Basic  :  Remote Controller, Power Cord, IR Extension Kit, HDMI Cable, Manual (ESG&EIG)
• Optional  :  Wi-Fi Dongle (AN-WF500)
